EXTENDE News - October 2020
TraiNDE UT 1.2 and Device Connected option are now available


  With TraiNDE UT 1.2, you can now directly plug our virtual mock-up into a real UT flaw detector!

Still no block and no couplant to handle, and you can train on your own system wherever your want! You will benefit from the TraiNDE UT advantages (easy and fast set-up, all students can work on the same block, pertinent exercises, educational tools, etc.) without having to learn a new system, as you will use your own. As a manufacturer, you can travel and show your UT flaw detector with our virtual mock-up, without needing to carry dozens of heavy blocks to demonstrate the advantages of your device to the world!

Take a look at our video, and visit our dedicated brand new TraiNDE website and our blog for more information, and of course, do not hesitate to contact us!
CIVA 2020 SP2 is now available

CIVA 2020

  In addition to the new add-on option CIVA Script, presented in the next entry of this newsletter, CIVA 2020 SP2 includes some noticeable enhancements, such as:
  • The capability to export in text files the results obtained within the metamodel analysis environment
  • In UT Analysis, a new Plug-In available to import "Prelude" acquisition data files (format by TPAC, *.stpacq) (see the related blog article)
  • In UT, a new option for the TCG built-in tool, which is now available in 3D for more accurate calibrations, and which is now also compatible with TFM data
  • In UT, the capability to include a hetereogeneous weld in Nozzle parametric geometries
  • In ET (2D Cyl.), the capability to define a ferrite core in Bobbin-probe-like tube inspections
Thanks to our continuous improvement commitment and to your feedback through our support service, this Service Pack also fixes some 100 issues in the related modules of the CIVA platform.

Users with a valid license and maintenance contract for CIVA 2020 should have received the download link for SP2 a few weeks ago through a dedicated emailing.

If you have any question about this update, you can contact our technical team at supportciva[at]extende.com .
New option available in CIVA: CIVA Script

CIVA Script

  A new add-on option, awaited by many users, is available with CIVA 2020 SP2: CIVA Script.

This paying option lets you drive CIVA through Script files.
Automation, optimization, characterization, customization, integration: with CIVA Script, you can save significant time and be much more efficient in your simulation works, especially for large scale computations and analysis work!

Take a look at our blog article for more information, and do not hesitate to contact us if you are interested by this great new feature!
You can also attend our webinar scheduled at 4PM CET on November 5th. Click here to register.
Online full training sessions

Training sessions

  Under the current circumstances, considering how travel has been made difficult by the pandemic, the EXTENDE team has decided to adapt and to open up online full training sessions to CIVA software.

Thus, for a training session usually under the course of 4 days of attendance, EXTENDE offers a format made of 2 online sessions of 2 days each (6 hours per day).

Feel free to contact us if you wish to register to one of these sessions.
Training dates for 2021

Training sessions

Training on reliability in NDE

  Our next intercompany training sessions are scheduled on the following dates:

CIVA – Introduction and Applications
UT and one additional module, in Massy, France:
  • From 15th to 19th March 2021
  • From 14th to 18th June 2021
  • From 20th to 24th September 2021
  • From 22nd to 26th November 2021
UT and either CIVA ATHENA2D or CIVA Analysis modules, in the U.S.A.:
  • From 10th to 14th May 2021
  • From 25th to 29th October 2021
Reliability in NDE, in Massy, France:
  • From 23rd to 25th March 2021 (in French French)
  • From 27th to 29th April 2021 (in English EnglishEnglish)
  • From 12th to 14th October 2021 (in English EnglishEnglish)
Feel free to contact us if you wish to register to one of these sessions.
First ever User Group Meeting in the U.S.A.

CIVA User Group

  On August 19th, 2020, CIVA users from across the U.S.A. and Canada virtually attended our first ever CIVA User Group meeting.

With approximately 40 people attending and four users presenting on their applications of CIVA UT, we plan to have another CIVA User Group meeting in 2021!

To learn more about this event and the presentations made, head to our blog.
CIVA Tip: Max beam only


  A new feature called "Max beam only" has been developed in the "Beam computation" module of CIVA UT to reduce the size of the result file and the computation time. Thanks to this option, it is possible to directly obtain the beam in Transmission/Reception at the end of the calculation process, whereas by default, a post-processing is necessary. [...] Read more
