MacSim

EXTENDE participated in the MACSIM project, supported by the National Reseach Agency (ANR).

MACSIM aimed at the possibility for the CIVA platform to integrate a new module simulating Acoustic Emission (AE) Non Destructive Testing.







Used for the inspection of numerous specimen like pressure equipment, nuclear submarines' boiler rooms or aeronautic structures, the developments resulting from the project will make the world benefit from a new simulation tool, unique for this method.





MACSIM gathered the following partners:

CEA LIST
CETIM
DCNS
EADS Innovation Works
UTC Compiègne (laboratoire Roberval)
EXTENDE

This project led to important progress in the field of Acoustic Emission simulation, and will probably allow future versions of CIVA to integrate this method in a new module.



Here are a few publications resulting from the MACSIM project:

[1] W. Ben Khalifa, K. Jezzine, G. Hello and S. Grondel, ‘Analytical modelling of acoustic emission from buried or surface-breaking cracks under stress,’
J. Phys.: Conf. Ser. 353, 012016 (2012).

[2] G. Hello, M. Ben Tahar, J.- M. Roelandt, ‘Analytical determination of coefficients in crack-tip stress expansions for a finite crack in an infinite plane medium,’
Int. J. Solids Struct. 49, pp. 556–566 (2012).

[3] W. Ben Khalifa, K. Jezzine, S. Grondel, G. Hello and A. Lhémery, ‘Modeling of the far-field Acoustic Emission from a crack under stress,’
J. Acoust. Emission, 30, pp. 137-151 (2012).

[4] T. Monnier, S. Dia, N. Godin and F. Zhang, ‘Primary calibration of acoustic emission sensors by the method of reciprocity, theoretical and experimental considerations,’
J. Acoust. Emission, 30, pp. 152-166 (2012).

[5] M. Ben Tahar, G. Hello and N. Bedrici, ‘Acoustic Emission during crack growth by a hybrid semi-analytical/BEM model,’
Proceedings of the 30th European Conference on Acoustic Emission Testing – 7th International Conference on Acoustic Emission, Granada (Spain), publiés en CD-ROM et sur http://www.ndt.net/article/ewgae2012/content/papers/108_BenTahar_Rev1.pdf, 10 p. (2012).

[6] A. Lhémery, M. Ben Tahar, F. Foucher, A. Mesinele, P. Recolin, F. Zhang, ‘Émission acoustique : simulation des contrôles – le projet ANR MACSIM,’
Actes du congrès COFREND, Dunkerque 2011, publié en ligne http://www.ndt.net/article/cofrend2011/papers/237.pdf, 10p. (2011).

[7] W. Ben Khalifa, K. Jezzine, S. Grondel, ‘Modélisation des ondes élastiques émises par un défaut sous contraintes,’ Actes du congrès COFREND, Dunkerque 2011, publié en ligne http://www.ndt.net/article/cofrend2011/papers/245.pdf, 10p. (2011).
